Description
Built-in with the cutting-edge image processing engine and USB 3.0 connectivity, the Avision AD280 breaks new ground in scanning performance by offering a blazing duplex scanning speed of up to 160 images per minute in Color, Grayscale, and Monochrome. Combining paper protection and reverse roller technologies, the AD280 balances high performance with exceptional feeding reliability across a wide variety of scanning situations.
Specification
|
AD280
|
| General Specification |
| Technology |
Color Charged-Coupled Device (CCD) |
| Light Source |
LED (Light Bar) |
| Document feeding mode |
ADF |
| Optical Resolution (dpi) |
600 |
| File Formats |
BMP, PNG, GIF, JPEG, Single-Page PDF, Multi-Page PDF,
Multi-TIFF, TIFF, RTF, TXT, OCR(for iScan only), XPS,
DOC, XLS, PPT, DOCS, XLSX, PPTX, HTML |
| Halftone Patterns |
Dither and Error Diffusion |
| Grayscale mode |
16bits input 8bits output |
| Color mode |
48bits input 24bits output |
| Memory Size |
128MB |
| Dimensions (WxDxH) |
Max:316 x 680 x 239 mm ( 12.4 x 26.8 x 9.4 in )
Min:316 x 191 x 168 mm ( 12.4 x 7.5 x 6.6 in ) |
| Weight |
4.7 Kg |
| Interface |
USB3.0 compatible |
| Power Consumption |
Operation:< 48W
Ready :< 16W
Sleep:< 1.2W
Off:< 0.22W |
| Acoustical Noise |
Operation < 55 dB
Standby < 45 dB |
| Recommended Daily Volume |
Up to 10000 pages |
| OS Support |
Win XP / Vista / Win 7 / Win 8 / Win 8.1 / Win 10 |
| Bundled Software |
Twain Driver ,ISIS Driver , AVScan , Button Manager , PaperPort SE 14 |
| FEATURES |
| Ultrasonic paper jam detection |
Yes |
| Long Paper Mode |
Up to 200dpi Color Duplex 236inch (6000mm)
Up to 300dpi Color Duplex 218inch (5540mm)
Up to 600dpi Color Duplex 59inch (1500mm) |
| Card Scan |
Embossed card (Thickness 1.25mm) |
| SCAN SIZE |
| ADF Minimum |
50 x 50 mm (2 x 2 in) |
| ADF Maximum |
216 x 356 mm (Legal) ( 8.5 x 14 in ) (Paper width up to 242 mm (9.5”) ) |
| ADF Capacity |
100 sheets ( 80 g/m² or 20 lb. Paper ) |
| Paper Thickness and Weight |
27g ~ 413 g/m² ( 7 to 110 lb ) |
| SCANNING SPEED |
| B/W @ 200dpi, A4 |
Simplex : 80 ppm
Duplex : 160 ipm |
| B/W @ 300dpi, A4 |
Simplex : 80 ppm
Duplex : 160 ipm |
| Color @ 200dpi, A4 |
Simplex : 80 ppm
Duplex : 160 ipm |
| Color @ 300dpi, A4 |
Simplex : 80 ppm
Duplex : 160 ipm |
|
